VDO - Veratron "OceanLink II" GPS - SOG Spidomeeter - kiirusnäidik ø 85mm 0-70 Knots /km/h 12/24V, must
OceanLink GPS-kiiruse näitajatel on integreeritud GPS-antenn, punktmaatriks LCD-ekraan ja NMEA2000-liides.
Elektroonilised GPS spidomeetrid odomeetri- ja läbisõidumõõdikuga LCD-ekraanil
Sisendandmed
Väljundandmed
VDO - Veratron "OceanLink II" GPS - SOG Speedometer ø 85mm 0-70 Knots /km/h /Mph 12/24V, black
Data sheet
Serie | VDO - Veratron OceanLink II |
Color | Black |
Installation dimension | 85 mm - 3 3/8 Inch |
Application | VDO Navigation |
Category | Speedometers |
Functionality | GPS Speedometers Multifunction |
Measurement range | 0 - 70 Kn - Km/h . Mph |
Operating voltage | 12 - 24 Volt DC |
IP front protection class | IP67 (IEC 60529) |
Input | NMEA-2000 |
Lens | Plastic double anti-fog |
Bezel model | Black round |
Bezel Interchangeable | Yes - Clip-on |
Warning light | Without |
Communication | NMEA 2000 - Veratron NavBox |
Sizes and mounting:
Installation (Hole) diameter and Outside diameter: | 85 mm - 3 3/8 Inch and 105 mm - 4 1/8 Inch |
Installation depth: | 50 mm |
Locking height with Spinlock nut: | Optional 0.5 mm - 20 mm |
Locking height with bracket: | 2 mm - 15 mm |
Flushmount: | Optional kit A2C59510864 |
Functionality:
Analog speed range: | 0 to 70 Knots - Km/h - Mph |
Display functionality: | Course Over Ground GPS-Time Trip Odometer Maximum speed |
Sensor signal analog speedo gauge: | RPM Inductive sensor RPM Hall sensor RPM Blockingoscillator sensor |
Signal input GPS speedometer: | NMEA 2000 |
Compatible sensors: | Built-in GPS Antenna |
Accuracy: | ± 2.5% of full scale reading |
Connection: | Hirschmann 8 pins MQS connectorm |
Power supply:
Operating voltage: | 11 - 30 Volt DC |
Current consumption without illumination: | < 100 mA |
Reverse polarity protection: | Yes |
Short circuit protection: | Not specified by VDO |
Dial & Pointer:
Deflection angle: | 320° |
Dial colour: | Black |
Dial Illumination: | Amber LED backlight 605nm |
Pointer: | White LED backlight |
Warning LED:: | Red (632nm) |
Programming: | Veratron USB software kit |
Design:
Model: | OceanLink GPS |
Lens: | Single - Anti-glare |
Standard bezel: | Round black (Interchangeable) |
Protection and standards:
Front protection class: | IP67 (IEC 60529) |
Rear protection class: | IP52 |
Relative humidity: | Maximum 95% |
Operating temperature: | -20°C to +70°C |
Storage temperature | -30°C to +85°C |
CE standard: | Yes |
DNV GL Certification: | Yes |
Mechanical shock continuous: | 25G - 6ms - 1Hz |
Mechanical single shock | 100G - 11ms |
Free fall test: | 1 Meter - 3x |
Housing flame retarding: | UL94-VD |
